Zora-3 Server

US$1,100.00
Preorder now

CPU, Memory and Storage

  • CPU: NXP i.MX8M Plus Quad, quad-core ARM Cortex-A53, 1.8GHz

  • NPU: AI/ML Neural Processing Unit, up to 2.3 TOPS (optional)

  • Real-Time Co-processor: ARM Cortex-M7, 800Mhz

  • RAM: 8GB, LPDDR4

  • Storage: 64GB eMMC flash, soldered on-board

Get notified by email when this product is in stock. We expect the first 100 units by end of February 2023.

CPU, Memory and Storage

  • CPU: NXP i.MX8M Plus Quad, quad-core ARM Cortex-A53, 1.8GHz

  • NPU: AI/ML Neural Processing Unit, up to 2.3 TOPS (optional)

  • Real-Time Co-processor: ARM Cortex-M7, 800Mhz

  • RAM: 8GB, LPDDR4

  • Storage: 64GB eMMC flash, soldered on-board

Network

  • LAN: 2x Gbit Ethernet, RJ45 connectors

  • WiFi and Bluetooth: 802.11ac WiFi and Bluetooth 5.3 BLE

    • Implemented with NXP 88W8997 module

    • 1x RP-SMA antenna connector

  • Cellular Modem (optional):

    • 4G/LTE CAT4 cellular module, Quectel EG25G

    • Worldwide LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage or

    • LTE CAT1 cellular module, Quectel EG21G

    • Worldwide LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage

    • SIM card socket

  • GNS: GPS Implemented with Quectel EG25 module

    • mutually exclusive with WiFi module ("WB" option)

I/O

  • USB: 1x USB3.0 port, type-A connector

  • Serial Ports: 1x RS485, 2-wire half-duplex Isolated, terminal-block connector

  • 1x RS232, Rx/Tx Isolated, terminal-block connector

  • CAN bus(NMEA2000): 1x CAN bus port Isolated, terminal-block connector

  • Digital I/O: 2x digital outputs + 2x digital inputs Isolated, 24V compliant with EN 61131-2, terminal-block connector

  • Debug: 1x serial console via UART-to-USB bridge, micro-USB connector NXP SDP programming port, micro-USB connector
