Expand your Zora-3 server's onboard storage with a dedicated SSD module. With 256 GB of fast NVMe storage, this module gives you room to keep extensive chart libraries, weather data, and system files downloaded directly to the server — ready for offline use the moment you leave the marina.
Want to go deeper?
Explore all the details in our guide →
Key Features
- Fast, reliable onboard storage — charts and data load instantly, even at sea with no internet connection (256 GB M.2 NVMe SSD)
- Built for the marine environment — operates reliably from –30 °C to 70 °C with a mean time to failure exceeding 200,000 hours
- Compact DIN-rail form factor — stacks neatly onto your Zora-3 gateway in position A, keeping your installation clean and serviceable
- High-endurance housing — ABS/PC construction engineered for long-term use aboard
Specifications
- Storage: M.2 NVMe 256 GB SSD
- Stack Limit: One SSD module per Zora-3 stack, installed in position A (next to main gateway)
- Housing: DIN rail mount (EN 50022), ABS/PC high-endurance material
- Dimensions: 110 × 20 × 95 mm (H × W × D)
- Weight: 110 g
- Operating Temperature: –30 °C to 70 °C
- Storage Temperature: –40 °C to 85 °C
- Humidity: 10 %–90 % (non-condensing)
- MTTF: > 200,000 hours
What's Included
- Zora-3 SSD Module (IFM-NVME) with pre-installed 256 GB NVMe drive
- DIN rail mounting hardware
Compliance & Warranty
Certified FCC, CE, and UKCA. Meets EMC standards EN 55032/5, EN 61000-6-2, and EN 61000-6-3, plus safety standard EN/UL/IEC 62368-1. Backed by a 5-year warranty.
